HOSPITAL ALARM

SDAL-MED L5



Download PDF Data sheet

Download PDF Conformity certificate


Typical application:
-Monitoring of 2nd stage pressure regulators for medical gases


Alarm unit SDAL-MED L5 functions:
•    5 digital alarm inputs ON/ OFF (pressure switches) with the following configuration:
     -Low/ High alarm pressure: O2, Med. Air and Low Vacuum or Evac. Air, CO2 and Low Vacuum
•    Alarm notification by 5 red LEDs
•    Acknowledge button for acoustic sound with alarm recovery function setting by a dip-switch (max. 15 min)
•    Test button for acoustic and visual periodic check
•    Programming jumper for inputs operation N.O. or N.C.
•    Local network interface with protocol SDAMNet Plus or ModBus (option)
•    Network address programming by a dip-switch;
•    Auxiliary output switch for external cumulative alarm indicators
•    Auxiliary output switch for external hooters
•    5 independent outputs reproducing the inputs status
•    Visual and acoustic indications about alarm status in accordance with European standard ISO 7396-1 and EN 60601-1-8
